使用与详细介绍/Brief Introduction：

全自動定位齿轮泵式膏体酱装罐机是爱子公司满足市面 各种需求开发管理的新好产品。这个机器运用SUS304不锈钢管齿轮泵式计量检定泵下达装罐，且集自動定位上盖、自動定位旋盖、电力设备自动化电力设备为合二为一，经济条件有用，占地赔偿范围小，范围广运用于制药企业、食材、农药杀菌剂、石油化工、画妆品等业的液状体木箱，适合GMP原则规定要求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

显著特点/characteristic：

◆按照轴向柱塞泵式的计量泵执行程序装罐，适用人群各种类型乳白色度介质，误差高；泵的组成部分按照快接式拆卸的学校，方便于的清洗、酒精消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆液压泵式压力容器检验泵活塞环环金属木头材质原料要根据该行业及全自动部分的多种按照硅聚氨酯，四氟乙稀或别的金属木头材质原料，特有商务活动按照卫浴陶瓷金属木头材质原料。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC控制机系统，调频可控硅调压，电脑工控设备层度高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不分装，主动计数器基本功能。Lack of bottle filling, automatic counting function◆装量修整简单，可以次修整全记量泵的充填量，也可针对于不同记量泵使用微幅修整；作业简单，修整怏速。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆灌装设备设备针头可设防滴漏问题部件，充填时潜进瓶底灌装设备设备，迟缓增涨，处理泡沫。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆设备可应用区别年纪的塑料瓶子，修整简单方便，可在间歇间内完成任务。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆整套装置按GMP的要求定制。The machine designed according to the requirements of GMP

技艺数据/technic parameter：

使用玻璃瓶的规格Size of bottles	20-1000ml（按照其请求制作厂）20-1000 - ml (according to your need）
实用塑料瓶子的直径Apply the bottle diameter	¢20-¢150mm
适用于盖子规格型号Apply the lid specifications	¢20-¢70mm
产生能力素质 production capacity	四头灌装生产线：1000-2500瓶/分钟 Four filling head: 1000-2500 bottles per hour 八头包装：2500-4000瓶/小 Eight head filling: 2500-4000 bottles per hour 12头灌装设备：4000-6000瓶/一小时 12 head filling: 4000-6000 bottles per hour
装量计算误差The load error	±1%
旋盖合格证率Screw cover percent of pass	≥99%
电源开关power supply	380V，50HZ
工作效率power	3.0KW
气动阀门gas sources	0.4-0.75MPA
速度慢调控speed control	直流变频空调可控硅调压variable speed
