的主要用途与介简/Brief Introduction：

该设备是转化成服食方式液玻璃窗钢瓶的新物品，徹底解决方法了已往服食方式液玻璃窗钢瓶的不良现象使用效果。此类灌封机所用到的的橡胶瓶，什么造句不要有洗瓶机、烘干箱机，更不要有紫外线灯消毒，可能同时灌封。这手机全主动理瓶、进瓶、装罐，装罐量比较保持稳定，无漏滴，无瓶不装罐。上盖、封口处率多达100%。此机水平最新，球设备体积较小、运营比较保持稳定、躁声低，操作流程返修、洗简单等显著特点，基本合乎GMP标准单位。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本类型有高转速和高速收费站不同年产量供您选择。Note: this model has two kinds of low speed and high-speed production for your choice.

亮点 Characteristic

◆机器使用于繁多易折瓶口服药液的计量灌装设备和粘口。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆大多数电器产品零件均采取有名的产品。All electrical components adopt famous brand◆该机工作形象化方面，无瓶不装罐，计量检验*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折橡胶瓶灌封机的大部分格局与的基本原理Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型口服药液易折pp瓶子灌封机具体理瓶器、理盖器、主转动系统性、云同步带时候送玻璃瓶置、空罐检漏部件、包装装置设备、去除部件、热融封装置设备、气动平衡机制小手指夹瓶装置设备、伺服高压电机高压电机时候上瓶装置设备与出瓶装置设备等组成部分。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆服务器用到的内服液易折橡胶瓶、盖有的是定是否干净区生产方式的，可以有泡脚药材经营许可资料证，故而瓶身与底盖经传输和"去外包服务"后可真接进到灌封间。在理盖器、理瓶器的电脑自动专向归类，去除返向底盖及瓶身底口朝下的瓶，使专向后的包材喂料有制度地进到推送轨道组件中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向生后胶囊液易折塑胶板材瓶在气力输送机轨道交通第二排Directional oral liquid after folding plastic bottles in conveying rail out easily

能力基本参数technical parameters：

型号model	NLGFY-40	NLGFY-80
装量区间The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
封好率Hot sealing intensity	》99%
装量粗差The load error	《1.5%
损坏率damage rate	《1.0%
工作电压power	2KW	3KW
电Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
含量 Weight	700Kg	800Kg
